NON-FLAMMABLE LIQUIDS SOLUTION
Garnet’s cost-effective tank truck measurement system is optimal for tank trucks hauling non-flammable liquids.
Equipping you with accurate digital measurements for non-flammable liquids in tanker trucks.
The SeeLeveL Annihilator system is designed for accurate level measurement of water, sewage or non-flammable chemicals. The all-digital design eliminates reading drift, ensuring long-term accuracy under all conditions without the need for costly and time-consuming re-calibration. The SeeLeveL Annihilator monitors up to three compartments eliminating the need for a display per compartment.
CORE SYSTEM
Level and Volume System
Models 806-B / 806-Bi
- Inside and Outside displays available
- Monitors up the 3 compartments per display
- 4 Alarm outputs
- One-Time calibration
- ¼” Resolution
- Truck powered
The SeeLeveL Annihilator uses Garnet’s reed switch technology to accurately sense the fluid level in a transport tank with ¼” resolution. The fixed reed position of the reed switches eliminates the need for recalibration during the life of the gauge. As fluid level rises and falls, the floats position is sent through a digital signal to one of the two display options user can choose from. The displays will show the volume of the tank in the preferred unit of measure the customers desires. With the 4 programmable alarm outputs, users can control lights, horns and pumps to streamline the pumping process.
806-B/806-Bi Wiring Diagram Multi Compartment Display Wiring diagram
- (1) 806B or 806Bi Display
- Programming Available Upon Request
- (1) 806AS Sender Bar
- (1) Carbon Steel Compression Fitting
- (1) Stainless End Cap
- Cut & Prep available upon request
- (1) 250-Stat_Float
- (1) 1″ NPT Couple
- (1) Anchor Support
- 2-5 Conductor cable
ADDITIONAL SUPPORT PRODUCTS
Truck Gauge Programmer
Model 817-USB
- Works with all 800 series displays
- Used to test sender bar displays and fiber optic cable
- Operates on four alkaline AA batteries with no memory loss
- 32 memory locations for storing calibration charts
- USB port interfaces with your PC or laptop running our truck gauge programming software
- Simulates both display and sender bar to simplify system testing
- Convenient hand-held aluminum enclosure helps to avoid errors due to interference and static electricity
817 Truck Gauge Programmer v3.2.2 (select the button below to download the software)
Remote Display & Data Portal
Model T-DP0301
- Communicates tank level data to ELD systems
- The display has a compact enclosure with a low profile design ideal for mounting on top of or underneath the dash, an overhead console, or under the seat. (2.7″ wide x 1.1″ high x 3.4″ deep)
- Standard 4-20 mA and 1-5V analog outputs and RS-232/RS-485 digital communication
- Operates on truck power
